LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
Kattintson a képre a kibontott nézet megnyitásához
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh
LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh

LILYGO® T-Embed ESP32-S3 CC1101 Low-Power Sub-1 GHz RF Transceiver PN532 NFC RFID I2C Module LCD Board Built-in Battery 1300mAh

Akciós ár
$80.38
Normál ár
$114.83
Megmented
$34.45 (31%)

Prices include VAT and any applicable duties.

Color:Transparent
Version:T-Embed
In stock, usually dispatched in 2-3 business days.




Specifications

MCU

ESP32-S3

Flash

16MB

PSRAM

8MB

Wireless Connectivity

2.4Ghz Wi-Fi

BLE 5

Onboard Functions

  • Boot + RST

  • IR Transceiver

  • Bat Detection: IO04

Onboard Button

Reset + Boot


CC1101 Low-Power Sub-1 GHz RF Transceiver

Frequency Bands

  • 300-348MHz

  • 387-464MHz

  • 779-928MHz



Optional Expansion

nRF24L01

Worldwide 2.4GHz ISM


I2C Transceiver Module

PN532

MAX98357A


Screen Specifications

Type

IPS TFT LCD

Resolution

170(H)RGB x 320(V)

Drive Chip

ST7789

Size

1.9-inch Diagonal

Interface

SPI






Version Differences

Version

T-Embed

T-Embed PLUS

CC1101

YES

YES

nRF24L01

NO

YES

Sample Code For Reference[Github]

If you need technical support please check below link to find more details.
