FNIRSI DS215H 2 in 1 Mini Repair tool, Dual channel

Highlights

◉ All-in-One Design: Combines a 50MHz dual-channel digital oscilloscope and 0-50kHz function generator in one portable device.

◉ High Performance: Built on FPGA+MCU+ADC architecture with 250MSa/s real-time sampling. Includes 13 built-in waveforms with adjustable frequency, amplitude, and duty cycle (up to 50kHz).

◉ HD Color Display: 3.5" IPS screen with 480x320 resolution for clear and vivid visuals.

◉ Easy Operation: Intuitive dial and button control with quick-access menus for efficient use.

◉ Certified Safety: Supports ±400V peak input with high-voltage protection and 1X/10X probe ratio settings. Fully compliant with GB/T 15289-2013 standards.

◉ Long Battery Life: Powered by a 1500mAh rechargeable lithium battery. USB-C charging (5V/1A) provides up to 4 hours standby.

FNIRSI-DS215H is a comprehensive and practical two-in-one dual-channel digital test instrument launched by FNIRSI, designed for the maintenance and R&D industries.

Key Features:

1. High-precision measurement: The FNIRSI-DS215H offers high precision with a sampling rate of up to 250MS/s and a 50MHz analog bandwidth, ensuring accurate measurements for various applications.

2. Wide voltage protection: Supports peak voltage measurements up to ±400V, offering reliable and safe performance in high-voltage scenarios.

3. Waveform storage: The device supports screenshot saving and viewing, making data analysis more convenient and efficient.

4. Signal generator functionality: It features 13 waveform outputs with a frequency range of 0-50 KHz, adjustable by a 1Hz step. The output parameters, including frequency, amplitude, and duty cycle, are fully adjustable to meet various needs.

5. Portable design: The device is equipped with a 3.5-inch display (480x320 resolution) for clear and intuitive visuals. Its compact and lightweight design makes it ideal for mobile use.

6. Long battery life: Powered by a 1500mAh rechargeable lithium battery, it supports up to 4 hours of continuous operation, ensuring long-lasting performance for on-the-go use.

7.Ideal for professionals: The FNIRSI-DS215H is designed to provide powerful and flexible features, offering users a portable and efficient tool for maintenance, R&D, and testing tasks.

Basic Parameter

1.Display:3.5-inch IPS high-definition color screen

2.Backlight:Brightness Adjustable

3.Power supply:TYPE-C(5V/1A)

4.Battery:1500mAh

5.Languages:中文, English, русский, 日本語, Español, Português, Deutsch, 한국어

6.Product size:≈66x110x19.5mm

7.Bare weight:≈138g

Parameter 1

1.Channel: Dual Channel

2.Bandwidth: 50 MHz

3.Real-time sampling rate: 250 MSa/s

4.Storage space: 14M

5.Time base range: 20ns/div - 20s/div

6.Vertical sensitivity: 10mV/div - 10V/div

7.Waveform display mode: Scroll

8.Vertical resolution: 8 bits

9.Input impedance: 1Μ ohm

10.Measurement data: Cycle, Freq, Vpp, Max, Min, Avg, RMS, Amp,Dduty cycle, waveform width

11.Probe attenuation factor: 1x / 10x

12.Input coupling: AC / DC

13.Trigger type: Rising edge / Falling edge

14.Peak voltage: ±400V

15.Trigger level range: 8 grids (positive and negative)

16.Trigger mode: Auto / Normal / Single

Parameter 2

1.Output waveform: Supports multiple waveform outputs

2.Waveform frequency: 0-50 KHz

3.Square wave duty cycle: 0-100%

4.Waveform amplitude: 0.1V - 3.0V

NO.1(Standard)

Host device *1

P6100 high vltage probe *1

Adapter *1

Alligator clip probe *1

Charging cable *1

User manual *1

Packaging color box *1

NO.2(Option)

Host device *1

P6100 high vltage probe *2

Adapter *2

Alligator clip probe *1

Charging cable *1

User manual *1

Packaging color box *1
