Sensor

  SONY CMOS 1/1.2" IMX585  4K sensor

Video output

  4K/1080P (HDMI Output)

Sensor size

 1/1.2 inch

Pixel size

 2.9 x 2.9μm

HDMI Resolution

 3840 x 2160 @60FPS(4K), 1920 x 1080P @60FPS;

Frame rate

 60FPS

Picture resolution

 3840 x 2160 (8 Mega pixel)

Video record

 Support 4K @60FPS Recording

USB interface

 Type-C 3.0  (USB 3.0)

USB Output resolution

 3840 x 2160 @30FPS; 1920x1080P @60FPS

Spectral response (wavelength)

 400nm~1000nm

Timed photo/video recording

 Support Timed photo/video recording

Dual-output

 Supports simultaneous HDMI/USB output

Comparison in one screen

 Support

Digital Zoom

 15X

White balance

 Support One-click/Auto/Manual White balance

Snap

 Support 4K still picture

Lens interface

 Standard C/CS interface

Video output interface

 HDMI/USB Dual output interface

Storage

 USB Flash Drive

PC systems

 Support Windows/Mac/ Linux system, with Measurement software(Gift)

Image measurement

 Support HAYEAR measurement software

Language

 Chinese, English

Working voltage

 DC 12V/1A

Size

 63x63x54(LxWxH)mm
