ESP32-C6 1.9 Inch Capacitive Touch Display IPS 170×320 LCD Camera Touch Option Supports WiFi Bluetooth Development Board ESP-32
Features:
1. Equipped with ESP32-C6 RISC-V processor, main frequency 160MHz, supports Wi-Fi 6 and Bt 5 functions.
2. Equipped with 1.9-inch LCD screen, resolution 170×320, 262K color display, clear and delicate picture quality.
3. Built-in QMI8658 six-axis sensor, supports motion posture detection, and expands more application scenarios.
4. Onboard Type-C interface, Micro SD card slot and lithium battery charging and discharging interface, convenient for storage and power supply needs.
5. Compatible with Pico pin interface, rich peripheral resources, easy to quickly develop HMI and other applications.
Product Features
This product uses ESP32-C6FH8 chip, supports 2.4GHz Wi-Fi 6 and BLE 5 Bluetooth functions, stacked 8MB Flash, onboard 1.9-inch LCD display, and can run GUI interface programs such as LVGL smoothly. The board has onboard peripheral resources such as the QMI8658 six-axis sensor, Micro SD card slot, and lithium battery charging, and also reserves a Pico-compatible pin interface. It has strong compatibility and scalability, and can quickly develop applications such as ESP32-C6's HMI.
Performance parameters
Equipped with ESP32-C6 high-performance 32-bit RISC-V processor, the main frequency is up to 160MHz
Support 2.4GHz Wi-Fi 6 (802.11 ax/b/g/n) and Bluetooth 5 (LE), onboard antenna
Built-in 512KB HP SRAM, 16KB LP SRAM and 320KB ROM, stacked 8MB Flash
Onboard 1.9-inch LCD screen, 170 × 320 resolution, 262K color, can clearly display color pictures
Onboard QMI8658 six-axis inertial measurement unit (3-axis acceleration, 3-axis gyroscope), can detect motion posture to expand applications
Onboard USB Type-C interface, can be used for power supply and download debugging, convenient for development and use
Onboard 3.7V MX1.25 lithium battery charging and discharging interface
Onboard Micro SD card slot, can be connected to an external SD card to store pictures or files
Onboard Pico Compatible interface, leading to a wealth of peripheral interfaces, strong compatibility and scalability
LCD screen parameters
Display panel: LCD
Display size: 1.9inch
Display resolution: 170 × 320
Display color: 262K
Display brightness: 500cd/m²
Contrast: 900:1
Communication interface: SPI
Driver IC: ST7789V2
Touch: Support (only with touch version)
Touch IC: CST816 (only with touch version)
Product list:
1X development board
